Specifications
Material properties
Open| Property | Value | Standard |
|---|---|---|
| RING MATERIAL | BRONZE (PB1) | - |
| RISER MATERIAL | COPPER | - |
| INSULATION MATERIAL | DMC | - |
RISERS properties
Open| Property | Value | Standard |
|---|---|---|
| TYPE | FLAT | - |
| LENGTH | 13mm | - |
| WIDTH | 5mm | - |
| THICKNESS | 1mm | - |
GENERAL INFORMATION properties
Open| Property | Value | Standard |
|---|---|---|
| KEY WAY (Y/N) | N | - |
| NUMBER OF CHANNELS | 2 | - |
| BORE SIZE | 22.4mm (H7) | - |
ELECTRICAL INFORMATION properties
Open| Property | Value | Standard |
|---|---|---|
| CURRENT MAX | 20amps | - |
| VOLTAGE MAX | TBC (IEC) | - |
