Specifications
Material properties
Open| Property | Value | Standard |
|---|---|---|
| Housing Material | Stainless Steel 303 | - |
Mechanical properties
Open| Property | Value | Standard |
|---|---|---|
| Lifetime, Million Cycles | >50 | ISO 281 |
| Start-up Torque (Nm) | 2.0 | - |
| Running Torque (Nm) Across all Temperatures | 0.5 - 1.5 | - |
Environmental properties
Open| Property | Value | Standard |
|---|---|---|
| IP Rating | IP68 | IEC 60529, IEC 61300-2-45:1999 |
| Operating Temperature Range (*c) | -30 to +85 | - |
| IP Rating Without Rated Connectors | IP65 | - |
General properties
Open| Property | Value | Standard |
|---|---|---|
| Overall Length (mm) | 59.84 | - |
| Mounting Flange Holes | 4 | - |
| No. Channels | 1 | - |
| No. Channels | 1 | - |
| Termination | ST | IEC 61754-2 |
| Wavelength | 1310 & 1550 Nm | - |
| Termination Polish | UPC | - |
Optical properties
Open| Property | Value | Standard |
|---|---|---|
| Insertion Loss (dB) | 1.5 / 3.0 | IEC 61300-3-4:2012 |
| Variation Insertion Loss (dB) | 0.5 / 1.0 | - |
| Return Loss (dB) | 30 / 33 | IEC 61300-3-6:2008 |
