Specifications
GENERAL INFORMATION properties
Open| Property | Value | Standard |
|---|---|---|
| IP RATING | IP65 | - |
| Mounting Flange (OD, Holes, PCD) | 3X Ø4MM HOLES @120° ON 41mm PCD | - |
| ROTOR AND STATOR CABLE LENGTH | 200mm PER EACH CHANNEL | - |
| NUMBER OF CHANNELS | 3 POWER CHANNELS | - |
| VOLTAGE RATING | 250V MAX | - |
| CURRENT RATING | DATASHEET REQUIRED FOR CONFORMATION | - |
| UNIT LENGTH | 69.75mm | - |
| FLANGE OD | Ø48mm | - |
| OPERATING SPEED | 1000 rpm | - |
| OPERATING TEMPERATURE | -30 TO 100°C | - |
| CIRCUIT RESISTANCE | 15-20 mO | - |
