Specifications
GENERAL INFORMATION properties
Open| Property | Value | Standard |
|---|---|---|
| IP RATING | IP51 | - |
| BORE SIZE | BETWEEN Ø19-Ø26mm (CUSTOMER TO CONFIRM WITH ORDER) | - |
| ROTOR SIDE TERMINATION | 6.3 MALE SPADE CRIMP - BLUE | - |
| STATOR CABLE LENGTH | 350mm | - |
| NUMBER OF CHANNELS | 8 POWER | - |
| VOLTAGE RATING | 250V | - |
| CURRENT RATING | 20A | - |
| UNIT LENGTH | 121mm | - |
| FIXING METHOD | 2X M4 GRUB SCREWS @90 DEG | - |
| OPERATING SPEED | 1000rpm | - |
| OPERATING TEMPERATURE | -30 TO 100°C | - |
| CIRCUIT RESISTANCE | 15-20 mO | - |
